Solara Vision Extreme Solar Panel (150W)
The world's toughest glass fronted solar panel - so strong you can drive over it! Designed and manufactured in Germany, the Vision Solar Panel is a truly extreme solar panel, for whenever you need something just that little bit stronger.
In some instances, such as where there is a chance of the solar panel being struck or damaged, or when the weather is 'extreme', the Vision panel offers you added peace of mind. One example is the roof of a motorhome, where there is the possibility of the panel being struck by low hanging branches. For marine applications, where weather conditions can sometimes be very harsh and there is always the possibility of the panel being accidentally hit or stood on, with a Vision panel, you won't need to worry about broken glass. Vision panels are guaranteed for use in a salt water (marine) environment.
Using a unique 'glass-glass' design, the Vision solar panel introduces new levels of robustness to the solar market. Each panel sandwiches the solar cells between two layers of a specially formulated version of laminated safety glass (similar to that in your car's windscreen). The result is a glass solar panel that you can walk on, stand on or even drive on.
|Model:||Vision 100||Vision 150|
|Open Circuit Voltage:||21.5V||22.4V|
|Short Circuit Current:||6.20A||8.83A|
|Series Fuse Rating:||20A||20A|
|Maximum System Voltage:||1000V||1000V|
|Temperature Co-efficient - Power:||-0.45%/ºC||-0.45%/ºC|
|Temperature Co-efficient - Voltage:||-0.36%/ ºC||-0.36%/ ºC|
|Temperature Co-efficient - Current:||0.03%/ºC||0.03/ºC|
|Weight:||9.0 kg||15.0 kg|
|Unit Dimensions (mm):||1237 x 557 x 40||1520 x 672 x 40|
*All technical specifications and images are correct at the time of publication, but are subject to change without notice.
